Description
EZVIZ Mini Pano 3MP fisheye IP camera with 360° panorama support
KEY FEATURES
1080p HD video
Works with Amazon Alexa & Google Assistant
Compatible with IFTTT
360° Panoramic viewing
Night vision
Two-way audio
Dual band WiFi 2.4GHz/5GHz
Micro SD NVR or cloud storage
App for iOS & Android
2 year warranty
Camera which covers whole area
Mini Pano is the first fisheye camera by EZVIZ for internal usage which supports 360° all-direction view. The camera is of high quality metal body designed in an excellent way with high corrosion resistance. Mini Pano provides detailed 3MP video which doesn’t lose the quality even when digitally zoomed. The fisheye is remotely controlled via EZVIZ application. Camera can be set both on wall or ceiling and doesn’t need any additional lens adjustment for all-round view.
FEATURES
The C6P (ez360 Pano) features a premium fisheye lens and 3-megapixel HDR sensor to support360° omnidirectional monitoring with four viewing modes: panoramic, expanded, dual-split screen and quad-split screen.A panoramic Wi-Fi camera offering complete coverage without any blind spots.
CONTROL EVERY ANGLE
The ez360 Pano is equipped with a 360° panoramic function so you can see any angle of the room by using your mobile device as a remote controller. You can cover the entire area with just one intelligent camera.
SEE THE WORLD THE WAY YOU WANT
Depending on your needs, select the preferred viewing mode like fisheye panorama, expanded view, split screen and quad-split screen. If 360-degree panoramic is not suitable for the area you want to cover, you can always split the screen into two or four views.
ALWAYS UP TO DATE
Whenever movement is detected, you get an instant notification via the app. You always have complete control.
STATE OF THE ART VIDEO QUALITY
With its 3 Megapixel sensor, you enjoy high-definition video. Even the smallest detail is crystal clear.
LISTEN IN AND TALK
Thanks to the built-in two-way audio, you will not be a mere observer but you are able to interact. Just open the EZVIZ app, start the real-time communication and decide whether you want to scare off the intruder or just your dog or talk with colleagues.
INTEGRATED EZVIZ SOLUTION
All EZVIZ cameras are smart home-enabled. You can connect the ez360 Pano to your EZVIZ door or window sensor. All-round safety made easy.
SEE WHAT’S HAPPENING, EVEN IN THE DARK
You don’t have to worry about late-night recordings. With the high-efficiency IR fill light, the camera will be able to see up to 7.5m in the dark. You can watch your entire room without making any noise or check up on your store or office during the night.
DUAL-BAND WI-FI
The ez360 Pano transmits via the Wi-Fi 2.4 or 5 GHz band/frequency. Therefore, you can always enjoy a stable, secure connection. Just switch bands to get the best transmission rate.
STORE AND SHARE IMPORTANT MOMENTS
The ez360 Pano has an integrated micro SD card slot that supports up to 128GB of storage (card not included). Ideal to keep a fun video, or to send images to the authorities in case of a burglary. You can also store the pictures and videos on the EZVIZ NVR video recorder.
SPECS
CAMERA
- Image Sensor – 3 Megapixel 1/2.8” Progressive Scan CMOS
- Minimum Illumination – 0.01 lux @(F2.2,AGC ON), 0 lux with IR
- Shutter Speed – Self-adaptive shutter
- Lens – 1.2mm@ F2.2, Horizontal angle: 180° Diagonal angle: 180°
- Lens Mount – M12
- Day & Night – IR-cut filter with auto-switching
- DNR – 3D DNR
- WDR – Progressive WDR
COMPRESSION
- Video Compression – H.264
- H.264 Type – Main profile
- Video Bit Rate – HD, Balanced and Smooth. Adaptive bit rate
- Max. Resolution – 1344×1344
- Image setting – Brightness, contrast, saturation, etc. (configurable via EZVIZ Studio)
- BLC – Support
NETWORK
- Storage – Support Micro SD card (Max. 128G)
- Smart Alarm – Motion detection
- Wi-Fi Pairing – SmartConfig (Wi-Fi One-Key Configuration)
- Protocol – EZVIZ cloud proprietary protocol
- Interface Protocol – EZVIZ cloud proprietary protocol
- General Features – Anti-Flicker, Dual-Stream, Heartbeat Messages, Mirror Image, Password Protection, Watermark
- Minimum Network Requirements – 2M
WIFI
- Standard – IEEE802.11a/b/g/n/ac
- Frequency Range – 2.412GHz ~ 2.462GHz/5.15GHz ~ 5.35GHz/ 5.725GHz ~ 5.825GHz
- Channel Bandwidth – Supports 20/40/80MHz
- Security – WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
- Transmission Rate – 11b: 11Mbps, 11g: 54Mbps, 11n: 135Mbps
GENERAL
- Operating Conditions – -30°C ~ 60°C, Humidity 95% or less (non-condensing)
- Power Supply – DC 5V ±5%
- Power Consumption – Max. 8W
- IR Range – Max. 7.5meters
- Product Dimensions – 70mm x 70mm x 70.6mm
- Packaging Dimensions – 109.5mm x 109.5mm x 123mm
- Weight – 222g
